LED Lit Lamps Silicone Thermal Conductive Pad 5.0W/MK, Grey Heat Sinking Rubber Sheet -50 To 200℃

LED Lit Lamps Silicone Thermal Conductive Pad 5.0W/MK, Grey Heat Sinking Rubber Sheet -50 To 200℃

Company profile

Ziitek company is a high-tech enterprise which dedicated to the R&D, manufacture and sales of the thermal interface materials (TIMs). We have rich experiences in this field which can support you the latest, most effective and one -step thermal management solutions. We have many advanced production equipments,full test equipments and fully automatic coating production lines which can support the production for high performance thermal silicone pad, thermal graphite sheet/ film, thermal double-sided tape, thermal insulation pad, thermal ceramic pad, phase change material, thermal grease etc. UL94 V-0, SGS and ROHS are compliant.

The TIF™800 Series is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.

Features

> Good thermal conductive 5.0 W/mK
> Moldability for complex parts
> Soft and compressible for low stress applications
> Naturally tacky needing no further adhesive coating
> Available in varies thicknesses

Applications

> CPU
> display card
> mainboard/mother board
> notebook
> power supply
> Heat pipe thermal solutions
> Memory Modules
> Mass storage devices
> Automotive electronics
> Set top boxes

Typical Properties of TIF™800 Series
Color	Gray	Visual
Construction & Compostion	Ceramic filled silicone rubber	***
Specific Gravity	2.65 g/cc	ASTM D297
Heat Capacity	1 l/g-K	ASTM C351
Hardness	40 Shore 00	ASTM 2240
Tensile Strength	35 psi	ASTM D412
Continuos Use Temp	-50 to 200℃	***
Outgassing(TML)	0.45%	ASTM E595
Dielectric Constant	4.5 MHz	ASTM D150
Volume Resistivity	5X1012Ohm-meter	ASTM D257
Fire rating	94 V0	equivalent UL
Thermal conductivity	5.0 W/m-K	ASTM D5470
