Custom Heat Transfer High Temperature Thermal Conductive Insulator Material Silicone Pad

Custom Heat Transfer High Temperature Thermal Conductive Insulator Material Silicone Pad
Custom Heat Transfer High Temperature Thermal Conductive Insulator Material Silicone Pad
video play

Large Image :  Custom Heat Transfer High Temperature Thermal Conductive Insulator Material Silicone Pad

Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: RoHs and UL
Model Number: TIS100-16-01
Payment & Shipping Terms:
Minimum Order Quantity: 1000PCS
Price: 0.1-10 USD/PCS
Packaging Details: 1000pcs/bag
Delivery Time: 2-3Work days
Payment Terms: T/T in advance
Supply Ability: 100000PCS/Day
Contact Now
Detailed Product Description
Products Name: Custom Heat Transfer High Temperature Thermal Conductive Insulator Material Silicone Pad Color: Gray
Density: 2.3g/cc Construction & Compostion: Ceramic Filled Silicone Elastomer / Fiberglass
Continuos Use Temp: -60 To 180℃ Thermal Conductivity: 1.6W/mK
Keywords: Thermal Conductive Insulator Material Thickness Range: 0.006(inch）/ 0.15mm
Application: GPU CPU Heatsink Cooling

Custom Heat Transfer High Temperature Thermal Conductive Insulator Material Silicone Pad



The TIS®100-16-01 Series of products are highly efficient insulating products and they also have thermal conductivity. It achieves the effect of both insulation and heat conduction by adding insulating silicone base material to the heat-conducting material.



Features:
> soft surface and goodthermal conductivity
> Excellent dielectric strength

> High voltage insulation, lowthermal resistance
> Tear-resistant, puncture-
> resistant


Applications:
> Car Battery & Power Supply

> Power semiconductors
> Audio and Video components

> Motor controllers

> Set top boxes
> Audio and video components
> IT infrastructure

Typical Properties of TIS®100-16-01 Series
Property Value Test Method
Color Gray Visual
Construction &Compostion Ceramic filled silicone elastomer /Fiberglass ******
Thickness range 0.006inch (0.15mm) 0.008~0.009inch (0.20~0.23mm) 0.010~0.018inch (0.25~0.45mm) ASTM D374
Tensile Strength(MPa) 30 ASTM D412
Density 2.3 g/cc ASTM D297
Continuos Use Temp -60 to 180℃ ******
Breakdown Voltage(V/mm) 3000 4000 5000 ASTM D149
Dielectric Constant @ 1MHz 5.5 ASTM D150
Volume Resistivity 4.0X1012 Ohm-meter ASTM D257
Fire rating 94 V0 UL(E331100)
Thermal conductivity 1.6W/m-K ASTM D5470



Product Specification
Standard Thicknesses

0.006inch~0.018 (0.15~0.45mm)



Standard Sizes
12" x 160"(304mm x 48.76M)

The TlS series can be die-cut into different shapes and provided. lf you need different thicknesses, please contact our company.

Custom Heat Transfer High Temperature Thermal Conductive Insulator Material Silicone Pad 0

Packaging Details & Lead time



The packaging of silicone insulation materials

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated


Company profile

With a wide range, good quality, reasonable prices and stylish designs, Ziitek thermal conductive interface materials are extensively used in Mainboards, VGA cards, Notebooks, DDR&DDR2 products, CD-ROM ,LCD TV, PDP products, Server Power products, Down lamps, Spotlights, Street lamps, Daylight lamps, LED Server Power products and others.


FAQ:



Q: Are you trading company or manufacturer ?

A: We are manufacturer in China.



Q: How do I place an order?

A:1. Click the "Sent messages" button to continue with the process.

2. Fill out the message form by entering a subject line, and message to us.

This message should include any questions you might have about the products as well as your purchase requests.

3. Click the "Send" button when you are finished to complete the process and send your message to us

4. We will reply you as soon as possible with Email or online

Q: How do I request customized samples?

A: To request samples, you can leave us message on website, or just contact us by send email or call us.



Q: What's the thermal conductivity test method given on the data sheet ?

A: All the data in the sheet are actual tested.Hot Disk and ASTM D5470 are utilized to test the thermal conductivity.
