Soft Thermal Pad Electrically Insulating Pad With Exceptional Thermal Conductivity For AI Processors AI Servers

Soft Thermal Pad Electrically Insulating Pad With Exceptional Thermal Conductivity For AI Processors AI Servers

Large Image :  Soft Thermal Pad Electrically Insulating Pad With Exceptional Thermal Conductivity For AI Processors AI Servers

Product Details:
Place of Origin: China
Brand Name: ZIITEK
Certification: UL
Model Number: TIF100-20-19S
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: Negotiation
Packaging Details: 1000pcs/bag
Delivery Time: 3-5work days
Payment Terms: T/T
Supply Ability: 10000/day
Detailed Product Description
Products Name: Soft Thermal Pad Electrically Insulating Pad With Exceptional Thermal Conductivity For AI Processors AI Servers Keywords: Soft Thermal Pads
Thickness: 0.25mm~5.0mm Density(g/cm³): 2.5
Application: AI Processors AI Servers Thermal Conductivity: 2.0W/m-K
Color: Yellow Construction: Ceramic Filled Silicone Elastomer

Soft Thermal Pad Electrically Insulating Pad With Exceptional Thermal Conductivity For AI Processors AI Servers



The TIF®100-20-19S Series is a well-balanced, general-purpose thermal pad.It offers good thermal conductivity and moderate hardness. This balanced design provides both excellent surface conformity and superior ease of use, making it capable of effectively transferring heat and providing basic physical protection for a wide range of electronic components.


Features:


> Good thermal conductive: 2.0W/mK
> Good softness and fillability
> Self-adhesive without the need for additional surface adhesives
> Good insulation performance


Applications:



> Al Servers
> Semiconductor Packaging
> Low-Altitude Aircraft
> Optical Communication Products
> 5G Base Stations

> CPU
> Display card
> Mainboard/mother board
> Notebook

> Home appliance industry
> Power module
> Wearable device
> Solar photovoltaic panel
> LED lighting fixtures



Typical Properties of TIF®100-20-19S Series
Property Value Test method
Color Yellow Visual
Construction & Compostion Ceramic filled silicone elastomer ******
Density(g/cm³) 2.5 ASTM D792
Thickness Range(inch/mm)

0.010~0.020

(0.25~0.5)

0.030~0.200

(0.75~5.00)

ASTM D374
Hardness 65 Shore 00 45 Shore 00 ASTM 2240
Continuos Use Temp -40 to 200℃ ***
Breakdown Voltage(V/mm) ≥5500 ASTM D149
Dielectric Constant 5.0 MHz ASTM D150
Volume Resistivity >1.0X1012 Ohm-meter ASTM D257
Thermal conductivity(w/m-K) 2.0 ASTM D5470
2.0 ISO 22007
Fire rating V-0 UL94 (E331100)

Standard Sheets Sizes:
Standard Thickness: 0.010" (0.25 mm)~0.200" (5.00 mm) with increments of 0.010" (0.25 mm)
Standard Size: 16"×16" (406 mm×406 mm)

Component Codes:
Reinforcement Fabric: FG (Fiberglass).
Coating Options: NS1 (Non-adhesive treatment),
DC1 (Single-sided hardening).
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive).

TheTIF®series is available in custom shapes and various forms.
For other thicknesses or more information, please contact us.
