High Thermal Conductive Metal Phase Changing Materials For Microprocessors Chipsets

Large Image : High Thermal Conductive Metal Phase Changing Materials For Microprocessors Chipsets

Product Details:

Place of Origin:	China
Brand Name:	Ziitek
Certification:	RoHs
Model Number:	TIC800M

Payment & Shipping Terms:

Minimum Order Quantity:	1000PCS
Price:	Negotiation
Packaging Details:	1000pcs/bay
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	100000pcs/day

Contact Now

Detailed Product Description

Name:	High Thermal Conductive Metal Phase Changing Materials For Microprocessors Chipsets	Color:	Silvery White
Thermal Conductivity:	18.9W/mK	Composition:	Alloy
Temperature Range:	-40℃～250℃	Density:	8.0g/cm³
Keywords:	Phase Changing Materials	Construction & Composition:	Bismuth Alloy
Name:	High Thermal Conductive Metal Phase Changing Materials For Microprocessors Chipsets	Color:	Silvery White
Thermal Conductivity:	18.9W/mK	Composition:	Alloy
Temperature Range:	-40℃～250℃	Density:	8.0g/cm³
Keywords:	Phase Changing Materials	Construction & Composition:	Bismuth Alloy
Name:	High Thermal Conductive Metal Phase Changing Materials For Microprocessors Chipsets	Color:	Silvery White
Thermal Conductivity:	18.9W/mK	Composition:	Alloy
Temperature Range:	-40℃～250℃	Density:	8.0g/cm³
Keywords:	Phase Changing Materials	Construction & Composition:	Bismuth Alloy
Name:	High Thermal Conductive Metal Phase Changing Materials For Microprocessors Chipsets	Color:	Silvery White
Thermal Conductivity:	18.9W/mK	Temperature Range:	-40℃～250℃
Density:	8.0g/cm³	Keywords:	Phase Changing Materials
Construction & Composition:	Bismuth Alloy
Highlight:	Microprocessors Chipsets Metal Phase Changing Materials , Microprocessors Chipsets Phase Changing Materials , High Thermal Conductive Phase Changing Materials

High Thermal Conductive Metal Phase Changing Materials For Microprocessors Chipsets

TIC^®800M is a new type of phase change thermal conductivity product made by mixing multiple metals, designed specifically to solve heat dissipation problems and improve application reliability. This material has high thermal conductivity,is not easy to evaporate,is safe and non-toxic, and has stable physical and chemical properties. When the temperature is higher than its phase transition temperature, the material will soften and undergo phase transition, which can tightly fill the small irregular contact surfaces on the device surface, forming a low contact thermal resistance thermal interface, thereby achieving excellent heat dissipation effect.

Features

> Excellent thermal conductivity
> Non toxic, environmentally friendly, and safe, meeting RoHS requirements
> Excellent long-term stability
> Thoroughly fill the contact surface to create low thermal resistance
> Not easily volatile

Applications

> Microprocessors
> Chipsets
> Graphic processing chips
> Set Top Box
> LED TV and LED lighting fixtures

Typical Properties of TIC^®800M Series
Property	Value	Test Method
Color	Silvery white	Visual
Form	Flaky solid	Visual
Construction & Composition	Bismuth Alloy	****
Density (g/cm³)	8.0	ASTM D792
Thermal conductivity(W/mK)	18.9	ISO22007
Specific heat capacity(J/g℃)	0.24	ASTM E1269
Resistivity (Ω-m)	＜10^-4	ASTM D257
Continuous Use Temp(℃)	-40 to 250℃	*****
Phase Change Temperature Range(℃)	>60	ASTM D3418
Solidification Range(℃)	＜57	ASTM D3418

Packaing:

TIC^®800M can be packaged according to customer requirements.

Usage Instructions:
After using this material, it is recommended to use suitable foam or gaskets to enclose the edges of the phase change metal,
ensuring that the material does not disperse or spread.
For more information about thermal conductive materials, please contact our company.
