High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module

High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module
High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module
High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module

Large Image :  High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module

Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: RoHs
Model Number: TIA808AL
Document: TIA800AL_Data Sheet.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 10SQM
Price: Negotiation
Packaging Details: 10RL/bag
Delivery Time: 3-7Work day
Payment Terms: T/T
Supply Ability: 1000SQM/Day
Contact Now

High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module

Description
Products Name: High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module Backing Type: Aluminum Foil
Adhesive Type: Acrylic Adhesive Color: White
180°Peel Adhesion (gf/inch) Steel, Immediate: ≥1200 Thermal Conductivity: 1.6 W/mK
Thickness: 0.008"/0.20mm Keywords: Thermal Adhesive Tape
Highlight:

Heat-conductive Acrylic Adhesive Tape

,

Double-sided Acrylic Adhesive Tape

,

Double-sided Thermal Adhesive Tape

High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module


The TIA®800AL Series is widely used for bonding heat sinks to microprocessors and other power consuming semiconductors. These tapes have strong adhesive strength and good thermal conductivity, aiming to replace traditional mechanical fixation and thermal conductive silicone grease,simplify assembly processes,improve product reliability,and are an ideal choice for solving the heat dissipation challenges of modern compact electronic devices.


High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module

Features

● Thermal Conductivity 1.6W/mK.
● High bond strength to a variety of surfaces
● Double sided pressure sensitive adhesive tape.
● High performance, thermally conductive acrylic adhesive
● allow for good conformability to irregular surfaces and good electrical isolation
● Easy Application
● Eliminates need for external hardware (screws, clips, etc.)
● Available with easy release tabs

Applications

● LED Power Supply
● LED Controller
● LED Lights
● LED Ceilinglamp
● Monitoring the Power Box
● AD-DC Power Adapters
● Piranha wroof and common lED module
● LED module for Channelletters
● SMD LED module
● LED Flesible strip, LED bar
● LED PanelLight

Typical Properties of  TIA®806AL Series
Products Name TIA®806AL TIA®806AL TIA®806AL Test Method
Color White
 Visual
Adhesive Type Acrylic Adhesive
 -
Backing Type Aluminum Foil
 -
Recommanded Operating Temperature(℃) -40~125
 -
Thickness (inch/mm) 0.006/ 0.15 0.008/0.20 0.010/0.25 ASTM D374
Breakdown Voltage(V) ≥ 1000 ≥ 1200 ≥ 1500 ASTM D149
Thermal Conductivity (W/mK) 1.6
 ASTM D5470
180°Peel Adhesion (gf/inch) Steel, Immediate ≥ 1200
 ASTM D149
180°Peel Adhesion (gf/inch) Steel, 24hrs ≥ 1400
 JIS K02378
Holding Power (H/inch) @25℃ ≥ 48
 JIS K023711
Holding Power (H/inch) @80℃ ≥ 48
 JIS K023711


Product Specifications

Standard Thickness:0.006"(0.15 mm),0.008"(0.20 mm),0.010" (0.25 mm)
Standard Size: 16"×100" (406 mmx 30.48 m)
Reinforcing Carrier:TIAB80oAL Series rolls can be reinforced with aluminum foil

The TIA Series can be provided with die-cutting into various shapes.
For different thicknesses or more information about thermally conductive materials,please contact our company.

Company Profile

Dongguan Zhaoke Electronic Material Technology Co., Ltd. was established in 2006. Is a high-tech enterprise specializing in the research, development, production and sales of thermal interface materials. We mainly produce: heat-conducting joint filler, low melting point thermal interface materials, heat-conducting insulator, heat-conducting adhesive tape, heat-conducting interface pad and heat-conducting grease, heat-conducting plastic, silicone rubber, silicone rubber foam, etc. We adhere to the business philosophy of "survival by quality, development by quality", and continue to provide the most efficient and best service for new and old customers with excellent quality in the spirit of rigor, pragmatism and innovation.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

UL

High-performance Heat-conductive Acrylic Adhesive Tape Double-sided Adhesive Thermal Adhesive Tape For Led Module
