Mobile Phone Double Sided Adhesive Tape PET Foil with good insulate
Z-paster2000-PE series is a insulators grade PET foil double coated with a special aggressive acrylic adhesive system with high quick stick, excellent acrylic cohesive strength, good low temperature performance and excellent high temperature resistance.
| Z-paster2000-PE series |
| Property |
2080-PE |
2130-PE |
2250-PE |
2380-PE |
| PET Foil Thickness (mm) |
0.025± 0.005 |
0.075± 0.005 |
0.188± 0.01 |
0.32± 0.01 |
| Total Thickness (mm) |
0.08± 0.015 |
0.13± 0.015 |
0.25± 0.02 |
0.38± 0.025 |
| Tensile (N / 25mm width) |
135 |
160 |
260 |
350 |
| Elongation (%) |
1.5 |
0.9 |
0.6 |
0.4 |
| Adhesion: Peel (PSTC #1) N / 25mm width |
32.8 |
32.8 |
32.8 |
32.8 |
| Adhesion: Shear (PSTC #7) 24+ hrs @ Kpa |
0.6 |
0.6 |
0.6 |
0.6 |
| Low Temperature Application (oC) |
17.9 |
17.9 |
17.9 |
17.9 |
| High Temperature Resistance (oC) |
120 |
120 |
120 |
120 |
| Low environmental Resistance (oC) |
-30 |
-30 |
-30 |
-30 |
| Release Liner |
83 lb.polycoated densified paper |
Packaging Details & Lead time
1.with PET film or foam-for protection
2. use Paper Card To Separate Each Layer
3. export carton inside and outside
4. meet with customers' requirement-customized
Lead Time :Quantity(Pieces):5000
Est. Time(days): To be negotiated
Company profile
Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.
FAQ:
Q: Are you trading company or manufacturer ?
A: We are manufacturer in China
Q: How long is your delivery time?
A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra cost?
A: Yes, we could offer samples free of charge
