55±5 Shore 00 RoHS Compliant Silicone Pads for Telecommunication Hardware

55±5 Shore 00 RoHS Compliant Silicone Pads for Telecommunication Hardware
55±5 Shore 00 RoHS Compliant Silicone Pads for Telecommunication Hardware
video play

Large Image :  55±5 Shore 00 RoHS Compliant Silicone Pads for Telecommunication Hardware

Product Details:
Place of Origin: China
Brand Name: ZIITEK
Certification: UL and RoHs
Model Number: TIF1100N-40-10F thermal pad
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: negotiation
Packaging Details: 1000pcs/bag
Delivery Time: 3-5 work days
Supply Ability: 100000pcs/day
Contact Now
Detailed Product Description
Hardness: 55±5 Shore 00 Keyword: Thermal Gap Pad
Dielectric Constant: 4.7 MHz Name: 55±5 Shore 00 RoHS Compliant Silicone Pads For Telecommunication Hardware
Part Number: TIF1100N-40-10F Density: 2.1 G/cm^3
Highlight:

55 Shore 00 Silicone Pads

,

Telecommunication Hardware Silicone Pads

,

RoHS Compliant Thermal Silicone Pad

55±5 Shore 00 RoHS Compliant Silicone Pads for Telecommunication Hardware



     The TIF1100N-40-10F is a silicone based, thermally conductive gap pad. Its unreinforced construction allows additional compliancy. This product has low hardness is conformable and is electrically isolating. The low modulus characteristic of the product offers optimal thermal performance with the ease of handling.



TIF100N-40-10F-Specification-sheet.pdf



Features

> Good thermal conductive: 4.0 W/mK

>Thickness: 2.5mmT

>hardness:55±5 shore 00

>Colour: Gray

>Moldability for complex parts
>Soft and compressible for low stress applications
>Naturally tacky needing no further adhesive coating











Applications

>Automotive engine control units

>Telecommunication hardware

>Handheld portable electronics

>Semiconductor automated test equipment (ATE)

>CPU

>display card



Typical Properties of TIF1100N-40-10F Series
Color
 Gray
Visual
Composite Thickness
Thermal Impedance@10psi
(℃-in²/W)
Construction &
Compostion
Ceramic filled silicone elastomer
***
10mils / 0.254 mm
0.16
20mils / 0.508 mm
0.20

Specific gravity

 2.1 g/cm3
ASTM D297
30mils / 0.762 mm
0.31
40mils / 1.016 mm
0.36
Thickness
2.5mmT
***
50mils / 1.270 mm
0.42
60mils / 1.524 mm
0.48
Hardness

 55±5 Shore 00
ASTM 2240
70mils / 1.778 mm
0.53
80mils / 2.032 mm
0.63
Thermal conductivity
4.0W/mk
ISO22007-2.2
90mils / 2.286 mm
0.73
100mils / 2.540 mm
0.81
Continuos Use Temp
-40 to 160℃
***
110mils / 2.794 mm
0.86
120mils / 3.048 mm
0.93
Dielectric Breakdown Voltage
>5500 VAC
ASTM D149
130mils / 3.302mm
1.00
140mils /3.556 mm
1.08
Dielectric Constant

 4.7 MHz
ASTM D150
150mils / 3.810 mm
1.13
160mils / 4.064 mm
1.20
Volume Resistivity
1.0X1012
Ohm-cm
ASTM D257
170mils / 4.318 mm
1.24
180mils / 4.572 mm
1.32
Fire rating
94 V0
equivalent
UL
190mils / 4.826 mm
1.41
200mils / 5.080 mm
1.52
Thermal conductivity
4.0 W/m-K
ASTM D5470
Visua l/ ASTM D751
ASTM D5470






























































Company Profile

Ziitek Electronic Material and Technology Ltd. is a R&D and production company, we have many production lines and processing technology of thermal conductive materials, owns advanced production equipment and optimized process, can provide various thermal solutions for different applications.





Packaging Details & Lead time



The packaging of thermal pad

1.with PET film or foam-for protection

2. use Paper Card To Separate Each Layer

3. export carton inside and outside

4. meet with customers' requirement-customized



Lead Time :Quantity(Pieces):5000

Est. Time(days): To be negotiated
