Gray High Temp Silicone Foam Sheet Shock-Absorbing Z-Foam 800-10FC For Automotive Industry

Gray High Temp Silicone Foam Sheet Shock-Absorbing Z-Foam 800-10FC For Automotive Industry
Gray High Temp Silicone Foam Sheet Shock-Absorbing Z-Foam 800-10FC For Automotive Industry
video play

Large Image :  Gray High Temp Silicone Foam Sheet Shock-Absorbing Z-Foam 800-10FC For Automotive Industry

Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: RoHs
Model Number: Z-Foam800-10FC
Payment & Shipping Terms:
Minimum Order Quantity: 1000PCS
Packaging Details: 1000PCS/bag
Delivery Time: 2-3 Work Day
Supply Ability: 100000PCS/Day
Detailed Product Description
Products Name: Gray Shock-Absorbing Z-Foam800-10FC Silicone Foam Sheet For The Automotive Industry Color: Grey
Density: 0.42±0.03 G/cm3 Compressive Stress,25%: 110±15kpa
Compression Permanent Deformation: ≤5.0% Tensile Strength: ≥0.4Mpa
Keywords: Silicone Foam Sheet Application: Electronic Products
Highlight:

Automotive Industry Silicone Foam Sheet

,

high temp silicone foam sheet

,

Gray Silicone Foam Sheet

Gray Shock-Absorbing Z-Foam800-10FC Silicone Foam Sheet For The Automotive Industry


Z-FoamTM 800-10FC is a medium stress silicone foamed material with excellent compressive and permanent deformation properties. Compared with the traditional carbon foam material, the material has excellent properties of high and low temperature resistance (-60-200℃), high flame retardant (V-0) and very low smoke concentration. In addition, the material has excellent resistance to aging and weather, making it an ideal material for shock absorption, cushioning, sound insulation, protection, insulation and fire protection.


Z-Foam800-10FC--Silicone-foam-specificatio-ns(E).p...

Features


>High and low temperature resistance - 60-200 ° C

>Good cushioning and high compression

>Resistance to ultraviolet light,ozone

>Provides enhanced sealing performance

>Compressed after using a good recovery



Application

>Car Battery
>Traffic Equipment
>Communication & Electrical Equipment
>Electronic products
>Charging Pile



Typical Properties of Z-Foam800-1030SC Series
Test procedure Unit Technical index Test method
Color **** Gray Visual
Density g/cm3 0.42 ±0.03 ASTM D1056
Compressive stress, 25% kpa 110±15 ASTM D1056
Compression permanent deformation % ≤5.0 ASTM D1056
Tensile Strength Mpa ≥0.4 GB/T 528-2009
Elongation % ≥100 GB/T 528-2009
Bibulous rate % ≤5.0 ASTM D570
Environmental testing ***** Qualifiled ROHS
Flame spread index ***** Qualifiled ASTM E162
Burning smoke concentration ***** Qualifiled ASTM E662-2015
Combustion of toxic gases ***** Qualifiled SMP 800-C-2009
Low temperature bending ***** -55℃ G57 Qualifiled ASTM D1056
Dielectric strength KV/mm ≥3.5 GB/T 1695-2005
Volume resistivity Ω.com ≥1.0*10^15 GB/T 1695-2005
Flame retardancy ratio ***** V-0 E331100
Thermal conductivity W/(m.K) 0.06 ASTM D5930



Gray High Temp Silicone Foam Sheet Shock-Absorbing Z-Foam 800-10FC For Automotive Industry 0

Company profile



Ziitek Electronic Material and Technology Ltd. is dedicated to developing composite thermal solution and manufacturing superior thermal interface materials for competitive market. Our vast experience allows us to assist our customers best in thermal engineering field.We serve customers with customized products, full product lines and flexible production, which makes us be the best and reliable partner of you. Let's make your design more perfect!


FAQ:

Q: Are you trading company or manufacturer ?
A: We are manufacturer in China.



Q: Do you accept custom orders ?

A:Yes , welcome to custom orders. Our custom elements including dimension , shape , color and coated on side or two sides adhesive or coated fiberglass. If you want to place a custom order , pls kindly offer a drawing or leave your custom order information .

Q: How much are the pads?

A: Price is depended on your size, thickness, quantity, and other requirements, such as adhesive and others. Please let us know these factors first so that we could give you an exact price.
