Heat-Resistant Waterproof Thermal Conductive Shockproof Epoxy Resin Potting Compound For Electronic Equipment
Product Summary:
TIETM380-45 is a one component, heatcured epoxy adhesive. lt has excellentthermal conductivity and bond strength.
TIETM380-45 is a good choice for highspeed production lines because it hasthe rheology to allow stencil printing anda fast, one component, heat cure.
TIE380-45.pdf
Feature
> Good thermal conductive: 4.5W/mK
> Good maneuverability andadhesion performance
> Low shrinkage
> Low viscosity, easy-to-gas emissions
> Good solvent resistance, water resistance
> Longer working hours
> Excellent resistance to thermal shock
Applications
> Automotive starters potting; General potting;
> Thermal detector potting
> Ferrite adhesion; TIP type LED; Good adhesion toaromatic polyester
> Relay sealant;Good adhesion to rubber, ceramics,PCB and plastics
> Power transformers and coils; Potting capacitors;Potting of small electrical devices
> Adhesion to metal glass and plastic;LCD & substrates adhesion;
> Coating and sealant; Coil ; IGBTS;Transformer; Fire retardant
> Optical / medical component adhesive
| Typical Properties of TIE380-45 |
| Chemical type |
Epoxy |
Test Method |
| Appearance uncured |
Gray Paste |
Visual |
| Appearance cured |
Dull Gray Solid |
visual |
| Components |
One Component |
****** |
| Heat Capacity |
0.7 l/g-K |
ASTM C351 |
| Key Substrates |
Metals, ceramics |
****** |
| Hardness |
92 Shore A |
ASTM 2240 |
| Continuous Use Temp |
-40~180℃ |
****** |
| Tensile strength Al/Al@25°C |
>2900psi |
****** |
| Thermal Conductivity |
4.5 W/m-K |
ASTM D5470 |
| Application Features |
| Color |
Gray |
| Viscosity@25°℃ |
150,00 cPs |
| Specific Gravity@25-℃ |
1.87 g/cc |
| Shelf life @25℃ |
10 Days |
| Shelf life @0℃ |
6 Months |
| Storage methods and temperature will affect the shelf life |
| Curing procedures |
| Curing temperature |
Curing time |
| 100℃ |
4 Hours |
| 125℃ |
2 Hour |
| 150℃ |
30 Minutes |
| 170℃ |
5 Minutes |
