4.0mm Thermal Gap Filler Gray Ul Recognized Silicone Fire Rating 94 V0 For Set Top Boxes

Large Image : 4.0mm Thermal Gap Filler Gray Ul Recognized Silicone Fire Rating 94 V0 For Set Top Boxes

Product Details:

Place of Origin:	China
Brand Name:	ZIITEK
Certification:	UL and RoHs
Model Number:	TIF1160-10UF thermal pad

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	negotiation
Packaging Details:	1000pcs/bag
Delivery Time:	3-5 work days
Supply Ability:	100000pcs/day

Contact Now

Detailed Product Description

Color:	Gray	Keyword:	Thermal Gap Pad
Volume Resistiviyt:	1.0X10^12 Ohm-cm	Name:	4.0mm Gray UL Recognized Silicone Pads For Set Top Boxes, Fire Rating 94 V0
Construction & Compostion:	Ceramic Filled Silicone Elastomer	Specific Gravity:	2.2 G/cc
Highlight:	4.0mm thermal gap filler , set top boxes thermal gap filler , 4.0mm thermally conductive gap filler pads

4.0mm Gray UL recognized Silicone Pads for Set Top Boxes, Fire Rating 94 V0

The TIF1160-10UF use a special process, with silicone as the base material, adding thermal conductive powder and flame retardant together to make the mixture to become thermal interface material. This is effective in lower the thermal resistance between the heat source and the heat sink.

Features

> Good thermal conductive: 1.5 W/mK

>Thickness: 4.0mmT

>hardness:75 shore 00

>Colour: gray

>Good thermal conductive
>Moldability for complex parts
>Soft and compressible for low stress applications

Applications

>Automotive electronics

>Set top boxes

>Audio and video components

>IT infrastructure

>GPS navigation and other portable devices

>CD-Rom, DVD-Rom cooling

Typical Properties of TIF1160-10UF Series
Color	gray	Visual	Composite Thickness	Thermal Impedance@10psi (℃-in²/W)
Construction & Compostion	Ceramic filled silicone elastomer	***	10mils / 0.254 mm	0.16
			20mils / 0.508 mm	0.20
Specific gravity	2.2 g/cc	ASTM D297	30mils / 0.762 mm	0.31
			40mils / 1.016 mm	0.36
Thickness	4.0mmT	***	50mils / 1.270 mm	0.42
			60mils / 1.524 mm	0.48
Hardness	75 Shore 00	ASTM 2240	70mils / 1.778 mm	0.53
			80mils / 2.032 mm	0.63
Outgasing (TML)	0.35%	ASTM E595	90mils / 2.286 mm	0.73
			100mils / 2.540 mm	0.81
Continuos Use Temp	-40 to 160℃	***	110mils / 2.794 mm	0.86
			120mils / 3.048 mm	0.93
Dielectric Breakdown Voltage	>5500 VAC	ASTM D149	130mils / 3.302mm	1.00
			140mils /3.556 mm	1.08
Dielectric Constant	3.9 MHz	ASTM D150	150mils / 3.810 mm	1.13
			160mils / 4.064 mm	1.20
Volume Resistivity	1.0X10¹² Ohm-cm	ASTM D257	170mils / 4.318 mm	1.24
			180mils / 4.572 mm	1.32
Fire rating	94 V0	equivalent UL	190mils / 4.826 mm	1.41
			200mils / 5.080 mm	1.52
Thermal conductivity	1.5 W/m-K	ASTM D5470	Visua l/ ASTM D751	ASTM D5470

Company Profile

Ziitek Electronic Material and Technology Ltd. provides product solutions to equipment product which generates too much heat affecting its high performance when using. Plus thermal products can control and manage heat to keep it cool to some extent.

Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

4.0mm Thermal Gap Filler Gray Ul Recognized Silicone Fire Rating 94 V0 For Set Top Boxes 0

FAQ:

Q: Are you trading company or manufacturer ?

A: We are manufacturer in China

Q: How long is your delivery time?

A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
