Car Batteries Thermal Conductive Pad With A Layer Of Insulation Fabric

Large Image : Car Batteries Thermal Conductive Pad With A Layer Of Insulation Fabric

Product Details:

Place of Origin:	China
Brand Name:	ZIITEK
Certification:	UL
Model Number:	TIF240-20-18S

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	Negotiation
Packaging Details:	1000pcs/bag
Delivery Time:	3-5work days
Payment Terms:	T/T
Supply Ability:	10000/day

Contact Now

Detailed Product Description

Products Name:	Car Batteries Thermal Conductive Pad With A Layer Of Insulation Fabric	Thickness:	1mmT
Thermal Conductivity:	2 W/m-K	Color:	Yellow
Keywords:	Thermal Conductive Pad	Application:	Car Batteries
Highlight:	thermally conductive pad , thermal conductive material , Car Batteries Thermal Conductive Pad

Car Batteries Thermal Conductive Pad With A Layer Of Insulation Fabric

The TIF240-20-18S thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base. Their flexibility and elasticity make them suited to the coating of the very uneven surfaces. Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.

Features:

> Good thermal conductive: 2 W/mK
> Fiberglass reinforced
> have a layer of insulation fabric
> Available in varies thickness

Applications:

> Car Batteries
> Cooling components to the chassis of frame
> High speed mass storage drives
> LED TV and LED-lit lamps
> RDRAM memory modules
> Micro heat pipe thermal solutions
> Automotive engine control units
> Telecommunication hardware
> Handheld portable electronics
> Semiconductor automated test equipment (ATE)

Typical Properties of TIF240-20-18S Series
Color	YELLOW	Visual
Construction & Compostion	Ceramic filled silicone rubber	******

Specific Gravity	2.75 g/cc	ASTM D297

Heat Capacity	1 l /g-K	ASTM C351

Hardness	45 Shore 00	ASTM 2240

Tensile Strength	45 psi	ASTM D412

Continuos Use Temp	-50 to 200℃	******

Dielectric Breakdown Voltage	>10000 VAC	ASTM D149

Dielectric Constant	5.5 MHz	ASTM D150

Volume Resistivity	7.8X10" Ohm-meter	ASTM D257

Fire rating	94 V0	equivalent UL

Thermal conductivity	2 W/m-K	ASTM D5470

Standard Sheets Sizes:

8" x 16"(203mm x 406mm) 16" x 18"(406mm x 457mm)
TIF™ series Individual die cut shapes can be supplied.

Peressure Sensitive Adhesive:

Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.

Reinforcement:

TIF™ series sheets type can add with fiberglass reinforced.
