foil High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness, -30 - 120 Degree

foil High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness, -30 - 120 Degree
foil High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness, -30 - 120 Degree foil High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness, -30 - 120 Degree foil High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness, -30 - 120 Degree foil High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness, -30 - 120 Degree

Large Image :  foil High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness, -30 - 120 Degree

Product Details:
Place of Origin: China
Brand Name: Ziitek
Certification: RoHs
Model Number: Z-paster2250-PE series
Payment & Shipping Terms:
Minimum Order Quantity: 1000PCS
Packaging Details: 1000pcs/day
Delivery Time: 2-3 work day
Supply Ability: 10000PCS/Day
Detailed Product Description
PET Foil Thickness: 0.188mm Total Thickness: 0.25mm
High Temperature Resistance (oC): 120 Low Environmental Resistance (oC): -30
Release Liner: 83 Lb.polycoated Densified Paper Adhesion: 32.8 Peel (PSTC #1) N / 25mm Width
High Light:

double sided self adhesive pads

,

double face tape

,

Strength PET Double Sided Tape

High Dielectric Strength PET Double Sided Tape with 0.25mm Thickness -30 - 120 Degree





        Z-paster2000-PE series is a insulators grade PET foil  double coated with a special aggressive acrylic adhesive system with high quick stick, excellent acrylic cohesive strength, good low temperature performance and excellent high temperature resistance.







Z-paster2000-PE series
Property 2080-PE 2130-PE 2250-PE 2380-PE
PET Foil Thickness (mm) 0.025± 0.005 0.075± 0.005 0.188± 0.01 0.32± 0.01
Total Thickness (mm) 0.08± 0.015 0.13± 0.015 0.25± 0.02 0.38± 0.025
Tensile (N / 25mm width) 135 160 260 350
Elongation (%) 1.5 0.9 0.6 0.4
Adhesion:    Peel (PSTC #1)                     N / 25mm width 32.8 32.8 32.8 32.8
Adhesion:    Shear (PSTC #7)              24+ hrs @  Kpa 0.6 0.6 0.6 0.6
Low Temperature Application (oC) 17.9 17.9 17.9 17.9
High Temperature Resistance (oC) 120 120 120 120
Low environmental Resistance (oC) -30 -30 -30 -30
Release Liner 83 lb.polycoated densified paper



Certifications:

ISO9001:2015

ISO14001: 2004 IATF16949:2016

IECQ QC 080000:2017

UL
