Electrically Insulating Thermal Pad With 2.0W/MK Thermal Conductivity For Thermal Management For Servers

Large Image : Electrically Insulating Thermal Pad With 2.0W/MK Thermal Conductivity For Thermal Management For Servers

Product Details:

Place of Origin:	China
Brand Name:	ZIITEK
Certification:	UL and RoHs
Model Number:	TIF400 Series
Document:	TIF400_Data Sheet.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1000pcs
Price:	Negotiation
Packaging Details:	1000pcs/bag
Delivery Time:	3-5work days
Payment Terms:	T/T
Supply Ability:	100000pcs/day

Contact Now

Electrically Insulating Thermal Pad With 2.0W/MK Thermal Conductivity For Thermal Management For Servers

Description

Products Name:	Electrically Insulating Thermal Pad With 2.0W/MK Thermal Conductivity For Thermal Management For Servers	Color:	Yellow
Thermal Conductivity:	2.0 W/m-K	Hardness:	65/45 Shore 00
Density(g/cm³）:	2.5	Breakdown Strength （V/mm）:	≥5.0
Flame Rating:	UL 94 V-0	Keywords:	Electrically Insulating Thermal Pad
Application:	Thermal Management For Servers
Highlight:	thermally conductive filler , thermal conductivity silicone , 2.0 W/m-K thermal Gap Filler

Electrically Insulating Thermal Pad With 2.0W/MK Thermal Conductivity For Thermal Management For Servers

Product Overview

TIF^®400 Series is a well-balanced, general-purpose thermal pad. It offers good thermal conductivity and moderate hardness. This balanced design provides both excellent surface conformity and superior ease of use, making it capable of effectively transferring heat and providing basic physical protection for a wide range of electronic components.

Key Features

Good thermal conductive: 2.0 W/mK
Naturally tacky needing no further adhesive coating
Soft and compressible for low stress applications
Available in various thicknesses

Applications

Cooling components to the chassis of frame
High speed mass storage drives
Heat sinking housing at LED-lit BLU in LCD
LED TV and LED-lit lamps
RDRAM memory modules
Micro heat pipe thermal solutions
Automotive engine control units
Telecommunication hardware
Handheld portable electronics
Semiconductor automated test equipment (ATE)

Typical Properties of TIF^®480 Series

Property	Value	Test Method
Color	Yellow	Visual
Construction	Ceramic filled silicone elastomer	-
Thickness range (inch/mm)	0.010"~0.020" (0.25~0.50mm) \| 0.030"~0.200" (0.75~5.00mm)	ASTM D374
Hardness (Shore 00)	65 \| 45	ASTM 2240
Density (g/cm³)	2.5	ASTM D792
Recommended Operating Temperature (℃)	-40-200℃	-
Breakdown Strength (V/mm)	≥5500	ASTM D149
Dielectric Constant @1MHz	5.0	ASTM D150
Volume Resistivity (Ohm-cm)	＞1.0×10¹²	ASTM D257
Thermal conductivity (W/m-K)	2.0	ASTM D5470 / ISO22007
Flame Rating	V-0	UL94 (E331100)

Product Specifications

Standard Thickness: 0.010" (0.25 mm) – 0.200" (5.00 mm) with increments of 0.010" (0.25 mm)

Standard Size: 16"×16" (406 mm×406 mm)

Component Codes

Reinforcement Fabric: FG (Fiberglass)
Coating Options: NS1 (Non-adhesive treatment), DC1 (Single-sided hardening)
Adhesive Options: A1/A2 (Single-sided/Double-sided adhesive)

The TIF series is available in custom shapes and various forms. For other thicknesses or more information, please contact us.

Company Profile

Ziitek Electronic Material and Technology Ltd was founded in 2006 and headquartered in Dongguan, Guangdong, is a high-tech enterprise specializing in heat conduction, heating, sealing and EMI products. In order to quickly respond to the global customer demand, the company has established production bases in Kunshan, Jiangsu, Taiwan Province and Viet Nam, and continues to promote the global distribution of production areas to ensure efficient delivery and localized services. Zhaoke's product system covers thermal interface materials, EMI shielding, heating products, foamed silicone seals and thermal engineering plastics, and is widely used in new energy vehicles, energy storage, AI servers, 5G communications, aerospace and other fields. The company has passed many certifications such as IATF16949 and ISO9001, and its products meet ROHS, REACH and UL specifications, serving the global market with reliable quality.

Certifications

ISO9001:2015
ISO14001:2004
IATF16949:2016
IECQ QC 080000:2017
UL

Frequently Asked Questions

Q: What Is a Thermal Pad?

A: A thermal pad is a pre-formed TIM designed to fill gaps between heat sources and heat sinks. Depending on the formulation, thermal pads can also provide electrical insulation and flame resistance.

Q: How Do I Choose the Correct Thermal Pad Thickness?

A: Thermal pad thickness should be selected based on the actual gap, dimensional tolerance, compression ratio and assembly pressure rather than simply choosing the thinnest option.

Q: Can Thermal Pads Be Customized?

A: Yes. ZIITEK can provide customized thermal interface solutions based on thickness, dimensions, shape, hardness and surface requirements.

Q: Does a Thermal Pad Need Compression?

A: Most thermal pads require a controlled amount of compression to improve interface contact. Excessive compression, however, may create unwanted mechanical stress.
