Easily attached white thermal silicone pad TIF 100-20-06E 2w/mK silicone heatsink pads -50 to 200℃ for routers

China Easily attached white thermal silicone pad TIF 100-20-06E 2w/mK silicone heatsink pads -50 to 200℃ for routers supplier
Easily attached white thermal silicone pad TIF 100-20-06E 2w/mK silicone heatsink pads -50 to 200℃ for routers supplier Easily attached white thermal silicone pad TIF 100-20-06E 2w/mK silicone heatsink pads -50 to 200℃ for routers supplier Easily attached white thermal silicone pad TIF 100-20-06E 2w/mK silicone heatsink pads -50 to 200℃ for routers supplier

Large Image :  Easily attached white thermal silicone pad TIF 100-20-06E 2w/mK silicone heatsink pads -50 to 200℃ for routers

Product Details:

Place of Origin: China
Brand Name: ZIITEK
Certification: UL and RoHs
Model Number: TIF 100-20-06E

Payment & Shipping Terms:

Minimum Order Quantity: 1000pcs
Price: negotiation
Packaging Details: 1000pcs/bag
Delivery Time: 3-5 days
Supply Ability: 100000pcs/day
Contact Now
Detailed Product Description
Thickness: 1 MmT Thermal Conductivity: 2 W/m-K
Hardness: 35 Shore 00 Dielectric Constant: 5.5 MHz
Fire Rating: 94-V0

Easily attached white thermal conductive pad TIF 100-20-06E 94 V0 2w/mK silicone heatsink pads -50 to 200℃ for routers


 The TIF100-20-06E Series thermally conductive interface materials are applied to fill the air gaps between the heating elements and the heat dissipation fins or the metal base. Their flexibility and elasticity make them suited to the coating of the very uneven surfaces. Heat can transmit to the metal housing or dissipation plate from the separate elements or even the entire PCB, which in effect enhances the efficiency and life-time of the heat-generating electronic components.

Features:

>  Good thermal conductive: 2 W/mK
>  Moldability for complex parts
>  Soft and compressible for low stress applications
> Naturally tacky needing no further adhesive coating

Applications:

Routers
RDRAM memory modules
Micro heat pipe
Automotive engine control units
Telecommunication hardware
Cooling components to chassis frame or other mating components
Home and small office network equipment
Handheld portable electronics
Plasma supply panels
Semiconductor automated test equipment (ATE)
Heat pipe thermal solutions
Memory Modules
Mass storage devices
Automotive electronics
Radios




Typical Properties of TIF100-20-06E Series
Color

white

Visual Composite Thickness hermalImpedance
@10psi
(℃-in²/W)
Construction &
Compostion
Ceramic filled silicone rubber
*** 10mils / 0.254 mm

0.48

20mils / 0.508 mm

0.56

Specific Gravity

2.32 g/cc

ASTM D297

30mils / 0.762 mm

0.71

40mils / 1.016 mm

0.80

Heat Capacity

1 l/g-K

ASTM C351

50mils / 1.270 mm

0.91

60mils / 1.524 mm

0.94

Hardness
 35 Shore 00 ASTM 2240

70mils / 1.778 mm

1.05

80mils / 2.032 mm

1.15

Tensile Strength


40 psi

ASTM D412

90mils / 2.286 mm

1.25

100mils / 2.540 mm

1.34

Continuos Use Temp
-50 to 200℃

***

110mils / 2.794 mm

1.43

120mils / 3.048 mm

1.52

Dielectric Breakdown Voltage
>10000 VAC ASTM D149

130mils / 3.302mm

1.63

140mils / 3.556 mm

1.71

Dielectric Constant
5.5 MHz ASTM D150

150mils / 3.810 mm

1.81

160mils / 4.064 mm

1.89
Volume Resistivity
7.8X10" Ohm-meter ASTM D257

170mils / 4.318 mm

1.98

180mils / 4.572 mm

2.07

Fire rating
94 V0

equivalent UL

190mils / 4.826 mm

2.14

200mils / 5.080 mm

2.22

Thermal conductivity
2 W/m-K ASTM D5470 Visua l/ ASTM D751 ASTM D5470




Standard Thicknesses:
0.010" (0.25mm)       0.020" (0.51mm)       0.030" (0.76mm)       0.040" (1.02mm)       0.050" (1.27mm)       0.060" (1.52mm)       0.070" (1.78mm)       0.080" (2.03mm)       0.090" (2.29mm)       0.100" (2.54mm)       0.110" (2.79mm)       0.120" (3.05mm)       0.130" (3.30mm)       0.140" (3.56mm)       0.150" (3.81mm)       0.160" (4.06mm)       0.170" (4.32mm)       0.180" (4.57mm)       0.190" (4.83mm)       0.200" (5.08mm)
Consult the factory alternate thickness.

Standard Sheets Sizes:
8" x 16"(203mm x 406mm)   16" x 18"(406mm x 457mm)
TIF™ series Individual die cut shapes can be supplied.

Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.

Reinforcement:
TIF™ series sheets type can add with fiberglass reinforced.
