Product Details:
Payment & Shipping Terms:
|
| Color: | Grey | Compaction: | 20% |
|---|---|---|---|
| Tensile Strength: | 45 Psi | Tear Strength: | 50 (8.8) Ppi (kN/m) |
| Operation Temperature: | – 40 To 200 ℃ | ||
| High Light: | high temp silicone gasket,foam gasket material |
||
Good cushioning and high compression silicone foam materials for high temperature and high pressure
Z-Foam800-1030C Series is the Ziitek research and development of silicone foam materials used for high temperature and high pressure.
We have different hardness and thickness specifications can be the user's flexible choice. At the same time, we can choose to join the fiberglass to increase the stability of the product size and improve the tear strength.
Spec of Z-foam800-10SC Series-REV01.pdf
Features
Can withstand high temperature 200℃
Good cushioning and high compression
Resistance to ultraviolet light,ozone
Provides enhanced sealing performance
Compressed after using a good recovery
Application
Car Battery
Traffic Equipment
Communication & Electrical Equipment
Electronic products
Charging Pile
|
Typical Properties of Z-Foam800-10SC Series |
||||||
|
Color |
Gray |
Visual |
Compression permanent deformation |
1.8% |
ASTM D1056-07 |
|
|
Hardness |
11.8 HA |
According to customer requirements |
Dielectric Constant |
120Hz 0.054 |
ASTM D150 |
|
|
Tensile Strength |
310 Kpa |
ASTM D412-06a(2013) |
Dielectric Strength |
1.9KV/mm |
ASTM D149 |
|
|
Tear Strength |
1.74 (kN/m) |
ASTM D624-2000(2012) |
Operation Temperature |
– 40 To 200 ℃ |
Ziitek Internal |
|
Standard Thicknesses:
